| makerom | |
| General | |
|---|---|
| Author(s) | 3dsguy |
| Type | PC utility |
| Version | 0.15 |
| Links | |
| Download | |
| Source | |
makerom is a tool which can be used to create NCCH, CCI, and CIA files.
There are two types of games format which are compatible with Nintendo 3DS which is the 3ds format and the cia format.You need to have a flashcart such as Sk. 3DSISO is a portal to download free 3DS CIA games, here you will find roms for both your 3DS console and games for CITRA an emulator with which you can play both PC and Android devices.The 3DS games on our site are from various regions such as EUR/USA/Japan. To enjoy them you just have to download the desired game from our 3DS games catalogue and unzip it, then transfer it to your R4 card. Converting a.3DS to.CIA For organizational purposes, copy each.3ds file you wish to convert to the /cias/ folder on your SD card Note that if you wish to convert a.3ds file that is already on a flashcart, you should follow Dumping a Game Cartridge.
Mac and Linux formatting can be done using standard tools available on those platforms. Getting Started. You’ll need a 64GB SD card or larger. You’ll also need a PC in order to do the transfer after you’ve successfully formatted the destination card, as well as the Nintendo 3DS and your old card. Videos to 2D/3D MJPG AVI files for the 3DS (can download directly from YouTube) Some of the file formats can be saved with replaced contents. Option for reading 3DS/CCI/CSU files from ZIP/7Z files. Just compress your 3DS/CCI/CSU file into a 7Z or ZIP (with any other file you want like NFO file) Then you can open it from 3DSExplorer.
- 1Format Overviews
- 1.2CCI
- 1.3CIA
- 2Using Makerom
- 2.1Command line
Format Overviews[edit]
NCCH[edit]
The native format storing code binaries and data archives for the 3DS is NCCH. NCCH files are comprised of:
- code/exheader/plainregion (used for code execution) (plainregion just lists included SDK library add-ons)
- icon (app title text, icon, homemenu settings, see here
- banner (cbmd + cwav, i.e. the upper screen banner/sound shown on the homemenu)
- logo (the splash screen displayed after an application is launched from the homemenu)
- romfs (read-only filesystem used to store resources)
Typical uses for NCCH files include:
- Executable image (code+exheader+icon+banner+logo+romfs)
- e-Manual archive (accessed from homemenu) (romfs)
- DLP child CIA archive (accessed from application) (romfs)
- Update Data archive (romfs)
- Standalone data archive (romfs)
- DLC index archive (icon+romfs)
- DLC archive (romfs)
CCI[edit]
The native format for gamecard images is CCI and is a NCCH container format. CCI files are limited to containing 8 NCCH files, and can contain NCCH files for applications titles only.
NCCH configuration for CCI[edit]
| NCCH | Required | Index |
|---|---|---|
| Executable image | YES | 0 |
| e-Manual archive | NO | 1 |
| DLP child CIA archive | NO | 2 |
| Update Data archive | NO | 7 |
CIA[edit]
The native format for packaging NCCH files for install is CIA, which is also a NCCH container format. CIA files are limited to containing 65535 NCCH files and can be used to contain NCCH files for any title type. CIA files also contain signed data used by the 3DS for general title management and DRM. Installing custom CIA files on a 3DS which also uses eShop/SysUpdates is unwise as conflicts will likely occur.
NCCH configurations for CIA[edit]
Applications (Application/DlpChild/Demo/Patch/SystemApplication):
| NCCH | Required | Index |
|---|---|---|
| Executable image | YES | 0 |
| e-Manual archive | NO | 1 |
| DLP child CIA archive | NO | 2 |
System Applet/Module:
| NCCH | Required | Index |
|---|---|---|
| Executable image | YES | 0 |
System Data Archives:
| NCCH | Required | Index |
|---|---|---|
| Data archive | YES | 0 |
DLC:
The number of DLC data archives in DLC varies for each DLC.
| NCCH | Required | Index |
|---|---|---|
| DLC index archive | YES | 0 |
| DLC data archive | YES | Varies |
3ds To Cia Converter For Mac Windows 7
Using Makerom[edit]
Command line[edit]
General Arguments
| Argument | Acceptable values | Notes |
|---|---|---|
| -f <format> | 'ncch'/'cxi'/'cfa'/'cci'/'cia' | Specify the output file format. 'ncch'/'cxi'/'cfa' has no affect, probably parsed without error for legacy support. |
| -o <path> | Valid file path. | Specify name/path for output file. Makerom will decided a name if this is not specified. |
| -v | not required | Enables verbose output. |
RSF Arguments
| Argument | Acceptable values | Notes |
|---|---|---|
| -rsf <path> | Valid file path | Specify the path to Rom Specification File(RSF). See below for creating RSF. |
| -D<NAME>=<VALUE> | This is used to substitute where '$(<NAME>)' exists in the RSF files with '<VALUE>'. (Uppercase isn't a requirement) |
Crypto Arguments
| Argument | Acceptable values | Notes |
|---|---|---|
| -target <target> | 't'/'d'/'p' | Specify key-chain. This affects encryption, signing and '-desc' template availability. t=test, suitable for homebrew. d=devkit(incomplete), suitable for devkits. p=retail(unusable), suitable for signing retail software? |
| -ckeyid <index> | Any value between 0-255 (inclusive). | Overrides the default common key used to encrypt CIA title keys. |
| -showkeys | none | Dumps loaded key-chain to stdout. |
NCCH Build Arguments
| Argument | Acceptable values | Notes |
|---|---|---|
| -elf <file> | Valid file path | Specify ELF. See below for creating ELF. |
| -icon <file> | Valid file path | Specify icon. |
| -banner <file> | Valid file path | Specify banner. |
| -desc <apptype>:<fw> | <apptype>='app'/'ecapp'/'demo'/'dlpchild'. <fw>='kernel version minor'. | Use a template for exheader/accessdesc. These are hard-coded, so not all firmwares have a template. A value from 1-7 can be used in place of 'kernel version minor'. A template shouldn't be used if the title needs 'special' permissions, the RSF must be configured fully. |
| -exefslogo | none | Include logo in ExeFS. Required for usage on <5.0 systems. |
Arguments useful for rebuilding a NCCH file:
| Argument | Acceptable values | Notes |
|---|---|---|
| -code <file> | Valid file path | Specify decompressed/plaintext exefs code binary. |
| -exheader <file> | Valid file path | Specify plaintext exheader binary. |
| -logo <file> | Valid file path | Specify logo. |
| -plainrgn <file> | Valid file path | Specify NCCH plain-region. |
| -romfs <file> | Valid file path | Specify an unencrypted RomFS binary. |
CCI Arguments
| Argument | Acceptable values | Notes |
|---|---|---|
| -content <path>:<index> | <path>=Valid file path. <index>=Any value between 0-7 (inclusive) | Include a built NCCH file in the CCI container. '-i' can be used instead of '-content'. |
| -devcci | none | Build a debug CCI? |
| -nomodtid | none | Don't modify the TitleIds of NCCH files included to match NCCH0 |
| -alignwr | none | Align the offset for the Card2 writable region to the end of the last NCCH in the CCI. |
CIA Arguments
| Argument | Acceptable values | Notes |
|---|---|---|
| -content <path>:<index>:<id> | <path>=Valid file path. <index>=Any value between 0x0-0xFFFF (inclusive). <id>=Any value between 0x0-0xFFFFFFFF (inclusive) | Include a built NCCH file in the CIA container. If <id> isn't specified, it will be generated randomly. '-i' can be used instead of '-content'. |
| -major <version> | Any value between 0-63 (inclusive) | Specify the version major for the title. This cannot be used with '-dver'. |
| -minor <version> | Any value between 0-63 (inclusive) | Specify the version minor for the title. This cannot be used with '-dver'. |
| -micro <version> | Any value between 0-15 (inclusive) | Specify the version micro for the title. |
| -dver <version> | Any value between 0-4095 (inclusive) | Specify the or '-minor'. |
| -dlc | none | Specify this flag when building a DLC CIA. |
| -rand | none | Use a random title key to encrypt CIA content. |
Examples[edit]
General examples:
Create CXI
Create CFA
Create CCI
Create CIA
Makerom supports building a NCCH file and including it automatically (as index 0) into a NCCH container:
Create CCI and CXI at the same time and include a CFA
Create CIA and CXI at the same time and include a CFA
Rebuilding CXI:
Creating RSF files[edit]
Inspired by Nintendo's format for their makerom, a yaml configuration file is required for creating NCCH files. CIA/CCI can be created without using a RSF file, but default settings will be used.
For CXI, RSF files can be used to specify permissions, and access control settings. Makerom can use default settings by use of the '-desc' option, which removes the requirement for specifying them in the RSF file.
Sample RSF to be used with '-desc': download (link broken)
Sample RSF to be used without '-desc': download
3ds To Cia Converter 4.1
Creating ELF files[edit]
The latest devkitARM used in conjunction with ctrulib can create ELF files compatible with makerom.
Convert 3ds To Cia File
ELF files that are created using the official SDK are also supported by makerom.
Compiling Source[edit]
For Windows a MinGW-W64/MSYS build setup is required.
For Linux, gcc/g++/make must be installed.
All additional libraries used by makerom (polarssl/libyaml) are included in the source, and are linked statically.
